New Generation DESIGN & STYLE
Exquisite detail and quality.
Sophisticated shape combined with soft curves and the attractive color with high quality two-tone metallic and pearlescent paintwork which complements any interior and appeals atmosphere of trust to the customer.
Feather-touch sensor button
The feather-touch sensor button used to interface with the screen enables sensitive and accurate operation.
Newly designed optical unit with further improved accuracy
The newly designed optical unit allows measurement of the minimum pupil diameter up to 2.0 mm and high-accuracy measurement.
Useful function for actual measurement such as display of reliability warning indicator has been added.
Improved side flaps,head rest and chin rest
Side flaps mounted to each side of the measurement window enabling to block out the light realizes high accuracy. The modified shapes of the forehead rest and the chin rest help to minimize stress of the patient.
The completely redesigned joystick with the shape and top button allows the operator to control the unit with more precise and instinctive movement.
Newly designed IOL Mode [color focus indicator]
A subject with IOL was conventionally difficult to measure but this newly designed IOL mode has made it much easier.
Scotopic & Photopic Pupil Diameter Measurement
Both scotopic and photopic measurements are available.
※ S.P.S：Scotopic Pupil Size
P.P.S：Photopic Pupil Size
Unique LCD Monitor
A swivel function to the left (30°) and a vertical tilt function (40°) have been added to the monitor unit. This swivel function allows measurement while supporting the patient.
Placido head 20rings and6292 measuring points.
Maximum measuring area10.6mm in 43Dipter.
Axial, tangential, elevation andrefractive in normalized, absolute,numeric and adjustable scales.
Also add layers(grid,rings,keratometric and pupil)andinterpolation.
3D corneal maps and 3D corneal indexes.
You can change the perspective angle bydragging the mouse both vertically andhorizontally.
Corneal profiles andCorneal structure.
4 different corneal maps areavailable.
Contact lens tools
You can obtain a suggested lens and seethe movement of the lens on the eye whileblinking.
This windows showsdifferent corneal indexes,like eccentricity, asphericityand shape factor. Alsoinclude the KISA% indexalgorithm for keratoconusdetection.
You can see the wholecorena, and measure usingrectangle, oval and lineshapes, clicking over theimage,and dragging themouse.
CT-1000 allows you to printthe current map displayed,in the Corneal Structurescreen, in a topographicreport, including theKeratometric Corneal Profileand the eye's image tovertify the detected rings.
50charts and various masks
Landolt, Letter, Child, Snellen, 50 kinds of charts, and Horizontal line, Vertical line, one chart, various masks can be selected by the remote control box.
Fast, slient chart disk rotation
It moves to the following chart in a maximum of 0.3 seconds.
User Program mode
2 kinds of programs can be selected. 48 kinds (maximum) of chart and mask are memorizable.
Room light switch
By using optional deviator, operation of a room light is available by the remote control.
Adjustment of the brightness
The brightness of the projector can be changeable by the control switch according to the brightness of the operation room.
- Lamp switch
- Room light switch
- Program switch (1,2)
- Chart/Mask switch
- Horizontal line switch
- Vertical line switch
- One chart switch
- Back switch
- Next switch
- Eyeball chart switch
- Mode dispay area
- Axis angle marks
- Abbe number
- Alignment status
- Spherical value
- Cylindrical value
- Axis value
- Prism value:X direction
- Prism value:Y direction
- Measurement increment
- Cylindrical sign
Color 5.7inch LCD screen
Color LCD screen produces superb colorful display of the measurement deta and icons for easier identification to select your desired choices for the measurement.
Measurement of various lenses
Measurement of various lenses, such as single lens, multifocal lens,progressive lens, frame lens and contact lenses, can be performed.
Easy lens plate without operating the lever
A troublesome lever does not need to be operated. Push the PUSH mark on the lens plate. The lens plate comes out.The lens plate always touches the bottom of the lens without operating the lever.
Automatic judgment for a progressive lens
- Far point
- Near point
- Add value
You can automatically check whether the lens is a progressive lens or not.
FAR POINT and NEAR POINT can be easily measured by directions and a graph display of color LCD screen.
Convenient contact lens measurement
If the convenient contact lens holder in the standard accessories is used, hard and soft contact lenses can be simply measured without touching by hand.
Cartridge-type marking pen
Uniform marking can be performed with a cartridge-type marking pen, and handling is also easy.
Printer is built in
Thermal Printer is built in. The measuing data can be printed if you push the print switch.
HI INDEX LENS measurement
You can select ABBE number to compensate the measurement for HI INDEX LENS.
RS-232C setting function
You can send the measurement data to an external computer through an interface. The data is sent using ASCII CODE.
Clear and Comfortable TFT Screen
Tilting color screen provides you with clear view from any position such as sitting and/or standing.
Brand NEW TFT Screen
Brand NEW TFT Screen
5.7inch TFT color screen visible from any angle. Capability of much more dynamic expression.
Hi-Speed UV measurement
Just holding the lens through the sensor, the display will easily indicate the UV measurement by the number of arrows (20% per arrow). Significant feature of 1% range measurement with built-in data memory.
Graphing Support for Progressive Lens
Progressive Auto Function
SLM-6000 recognizes progressive lens automatically and start the progressive measuring mode by just placing the lens.
"Dual Nose Pad" PD Measurment
With our unique "Dual Nose Pad" the PD measurement is much quicker and easier. Higher work efficiency on left and right lens measurement.
To work efficiently, frequently used function can be memorized in the customize button.
Speedy Thermal Printer
Quick data print with built-in printer.
Easy to reload printing paper. (Paper size: 58mm)
RS-232C and USB interface for expanded compatibility.
Contact Lens Measurement
By using the enclosed special contact lens holder mount, you can comfortably measure the contact lenses.
- Rotation Adjustment Knob
- Mounting Bracket
- Tilt Clamp Knob
- Reading Rod Clamp Screw
- Reading Rod Holder
- Spirit Level
- P.D. Scale
- Forehead Rest Knob
- Leveling Knob
- P.D. Knob
- Vergence Lever
- Auxiliary Lens Scale
- Auxiliary Lens Knob
- Strong Sphere Control
- Corneal Aligning Device
- Sphere Power Scale
- Weak Sphere Dial
- Cylinder Axis Scale
- Cylinder Axis Indicators
- Cylinder Axis Reference Scale
- Cylinder Power Scale
- Cross Cylinder Unit
- Cylinder Power Knob
- Cylinder Axis Knob
- Rotary Prism Unit
Thin, clear design that fits and matches to any room or atmosphere.
IMAGE and MOVIE VIEWING
Random slide show or movie can be played by using external USB insert.
VARIETY OF CHARTS INCLUDING SPECIALIZED CHARTS
Chart is available in Letter, Number, Alphabets, Children, Landolt and Snellen. In addition, total of 16 specialized charts are available to suit your operation.
CROSS HAIR WORTH 4 BINOCULAR
CROSS RING DOTS FIXATION
LETTER R/G R/G ASTIGMATISM STEREOPSIS CYCLOPHORIA HORIZONTAL ANISEIKONIA VERTICAL ANISEIKONIA PHORIA WITH FIXATION
Large LCD display with backlight for easy operation and clear view in the dark room.
